Lighting Layout of Indoor Substations

We prepare Lighting calculations and lighting layout drawings for indoor GIS halls and Medium voltage Substation buildings in India and Abroad. The drawings are prepared on the basis of lighting calculations done by Lighting software like Dailux/Calculux etc. and Clients specification. Either high pressure Sodium vapour lamps OR Metal halide lamps OR Fluorescent lighting fixtures OR LED indoor lighting fixtures are used for indoor illumination. Small power distribution scheme is also part of this drawing.

Our engineers are repetitively preparing suchdrawings for each and every project and thus have gained high expertise inpreparing similar drawings. Due to our high skill, we can deliver the drawingat very short time and at a very attractive rate.
